► Texture Adjustments ◄

Open Adjustments_Flip.shader file and try changing (line 19):
from

Code (CSharp):

1. return (tex2D(_MainTex, lerp(i.uv, i.uv * -1, _Flip)));

to

Code (CSharp):

1. return (tex2D(_MainTex, lerp(i.uv, 1 - i.uv, _Flip)));

VacuumShaders - Facebook Twitter YouTube



Good job !
It's working on IOS now

Edit : Seems to be working correctly with Andoid + IOS now !

Awesome



Hi Arkhivrag,
Sorry to bother you again with this. But I really need the "Multithreaded Rendering" to be checked in order to avoid an issue with an other plugin.

Could you try to find a way to make it works ?

Best regards,
Seb



Hey there, I just bought your asset because I needed to use the Hue/Saturation/Lightness Shader for changing an image - the same way as I would do it in photoshop. Sadly I just found out that this shader is missing one small option which photoshop has -> the colorize option. Is it possible to add this, otherwise I can't use this asset sadly

Thanks in advance,
Oliver



Added to a wishlist.



VacuumShaders - Facebook Twitter YouTube



Thanks that would be really great. Even though I found some kind of a workaround for now with HSL (used only for the lightness) + Color Overlay (V set at 128) - so then I can reuse my photoshop settings for Hue and Saturation with a convert from HSV to HSL.

BTW is it possible to reuse the Presets in the API or can we use the presets in the Editor only (didn't find any info on this but it looks like it only works in the editor).

That would be also a great feature to add...



Hello, I bought this asset recently and it works very well. But I found some features I want isn't in it.

1. Image crop. It's not hard to implement by myself but it will be very handy if can be added to the asset.
2. Is it possible to add a feature like this: https://www.assetstore.unity3d.com/en/#!/content/57720? I'm using it now but very slow.

Thank you!



Update v2017.1 includes Crop and Edge Padding tools.



VacuumShaders - Facebook Twitter YouTube



Nice! Is the crop done on the gpu? cpu?



Crop is done on the GPU. Just update to v2017.2



VacuumShaders - Facebook Twitter YouTube



Thank you so much!!



Get this error on import

TypeLoadException: Could not load type 'UnityEngine.ImageConversion' from assembly 'VacuumShaders'.
VacuumShaders.TextureAdjustments.TextureAdjustments_Resources.LoadTexture (UnityEngine.Texture2D& _texture2D, System.String _pro, System.String _free, TextureWrapMode _wrapMode)
VacuumShaders.TextureAdjustments.TextureAdjustments_EditorWindow.Load_Resources ()
VacuumShaders.TextureAdjustments.TextureAdjustments_EditorWindow.OnGUI ()
System.Reflection.MonoMethod.Invoke (System.Object obj, BindingFlags invokeAttr, System.Reflection.Binder binder, System.Object[] parameters, System.Globalization.CultureInfo culture) (at /Users/builduser/buildslave/mono/build/mcs/class/corlib/System.Reflection/MonoMethod.cs:222)

and the Texture Adjustments windows can't open

empty project, and empty scene with
Unity 5.6.2f1 & latest TextureAdjustment version on Assets Store



'UnityEngine.ImageConversion' is part of Unity 2017.1 engine and it can not be loaded in Unity 5.6
Solution: Completely remove plugin from the project, clear Asset Store cache and download new version from the store.
Note, there are several plugin versions on the store for different Unity versions.



VacuumShaders - Facebook Twitter YouTube



Hey @Arkhivrag

I need to rotate my Texture2D 90 degrees and also change the ratio during runtime.

The texture is with different width and height.



Yes, you can, with included Rotate and Resize tools (in editor and runtime)




VacuumShaders - Facebook Twitter YouTube



Hi
In my job, I need a tool to help me rotate texture2D and save it.
So, I use Adjust_Rotate to rotate Texture2D than I use EncodeToJPG() and File.WriteAllBytes() to save it.

Finally, the photo in file system is original photo. no any rotation.

Jason



Are you sure you are saving adjusted texture and not the original one?
Does it happen in editor or in build?
What Unity version are you using?



VacuumShaders - Facebook Twitter YouTube



Hi
I test it on android phone(sony xp) and unity version is 5.6.0

I am sure saved texture is adjust texture



Inside Editor it's very easy to check if texture is adjusted, may be with public Texture2D variable.
In Build you will have to include the shader that is used by an adjustment (it has the same name) to the Always Included Shaders array of Graphic Settings.



VacuumShaders - Facebook Twitter YouTube



Hello Arkhivrag,
I'm manipulating HD photos (flip and rotate) and I was previously using a CPU method in order to do that.
I'm switching to your plugin and the performance is great but the result is not as good.
I'm using this parameters :

Code (CSharp):

1. Adjust_Flip photoFlip = new Adjust_Flip();
2. Adjust_Rotate photoRotate = new Adjust_Rotate();
3.
4. photoFlip.vertical = true;
5. photoFlip.horizontal = false;
6. photoRotate.angle = Adjust_Rotate.ANGLE._90_CCW;

And here is the comparison with my previous method (same quality settings) :


As you see with texture adjustments the texture is a little more blurry with some aliasing.
As I'm manipulating HD photos I don't want to lose the details :/

You can have a closer comparison on your desktop if you download them :
https://img15.hostingpics.net/pics/878144TestCPU.jpg
https://img15.hostingpics.net/pics/641893TestTextureAdjustements.jpg

Is is possible enhance the quality ouput ?
Thank you very much !!!

Seb



Also is it possible to add a "watermark" GPU feature (combine 2 Texture2D) ?
Thank you



Texture Adjustments receives input texture from Unity engine and it may be different (a little bit) then the original file you have on your hard drive. After that texture is send to GPU -> transformed using shaders -> returned from GPU -> converted to Unity texture. After all these passes generated texture can not be 100% identical as the original file.

I've tested your images and exporting generated texture in PNG format gave me the same result (about 99% identical to original), but JPG file had significant quality drop.

Bookmarked for the next update.



VacuumShaders - Facebook Twitter YouTube



Hi there,
Can i use your plugin to convert a picture to pixelated look like this one?
http://lh4.ggpht.com/BULvCChghTCe_3jPobNc8FaCuvyxqlZMY50mlKx5TWS_AV3sS_d_kk6a9Y1boGhn3w=w300

If so , is there any sample scene?
Thanks



There is no Pixelate adjustment included.



VacuumShaders - Facebook Twitter YouTube



Any plans to add it in future?



May be Photoshop style, but it will not create such perfect pixelate image especially with outline.



VacuumShaders - Facebook Twitter YouTube



for the real-time API, is this working with AT2 ?



What is AT2?



VacuumShaders - Facebook Twitter YouTube



Sorry. Amplify Texture 2 with simple UV.

My bet is that it doesn’t because I cannot imagine AT2 revirtualizing the texture.



Even photoshop style is welcomed



Update will be available in several days.




VacuumShaders - Facebook Twitter YouTube



Do you have a release date more or less for the "watermark" feature ?
Thank you,

Seb



version 2017.3 already includes 'Watermark' feature.
Check it in ColorOveraly blend modes.



VacuumShaders - Facebook Twitter YouTube



You are amazing



I like your pixelate feature. Any method to get the color value(RGB) of every pixel grid?



With included API - no.



VacuumShaders - Facebook Twitter YouTube



We'd like to use your plugin to pixelate a static image and get RGB color value of each pixel, can you add the relative API to the plugin?



We'd like a customized version of your plugin, anyway to send an email to you?



No, sorry. Such method is out of the scope of this plugin.



VacuumShaders - Facebook Twitter YouTube



@Arkhivrag Can you please add support of RGB to BGR and Vice Versa of an image?
https://itunes.apple.com/us/app/full-spectrum-camera/id1287223058?mt=8

Thanks



Channel > Swap




VacuumShaders - Facebook Twitter YouTube



wow



Hi!
How can i move content of Texture2D using API inside of texture?
Help, please



Is it possible to use the API to do a color replace with a mask? And is it possible to add making the color replace target a gradient?



Almost everything that can be done inside Editor window, can be done with API too.
Color replace with mask - Yes.
Color replace target gradient - No.



VacuumShaders - Facebook Twitter YouTube



Working on update with new improved editor, more adjustments and Linear color space support.





VacuumShaders - Facebook Twitter YouTube



Hi @Arkhivrag
As in this preview, its clear that your code both knows the cell size as well as the color it apply to that cell? So its theoretically possible to return a 2D Array ( a representation of grid) where each cell (array[x][y]) contains color value of that image's cell?

I'd really appreciate if you provide this enhancement

Thanks



You can try resize texture to have the same dimensions as cell count in Pixelate tab and then use Unity's GetPixels method.
After resizing set textures filter mode to Point.



VacuumShaders - Facebook Twitter YouTube



Will try and let you know how it goes. Thanks



As im doing it dynamically on runtime, so only property i see is cellSize
so resizing whole image to CellSize doesnt seem to work.

Can you please explain in detail
